DAWSON
DAWSON MACHINERY & MOULD GROUP
Extrusion Blow Molding Machine ABLB65
Consider an HDPE blow molding machine, which uses advanced technology and precision craftsmanship to produce plastic containers of various specifications. Whether it is a 50 ml small bottle or a 5 liter Jerky can, this blow molding machine can handle it. Its bilingual operation panel makes operation more convenient and is not subject to language restrictions, allowing operators to operate and monitor easily. In addition, the blow molding machine also adopts automatic configuration from world-renowned brands to ensure the stability and reliability of the equipment. Users can easily realize the automated operation of the production line through simple settings, improve production efficiency and reduce production costs.
Machine Model | Max. Bottle size | Production forecast | |
ABLB65II | Double Station/ 1 Head | 3.5L | 240~260 BPH |
Double Station/ 2 Head | 1L | 530~550 BPH | |
Name | Units | ABLB65II | ABLB75II |
Max.product volume | L | 3.5 | 8 |
Screw diameter | MM | 65 | 75 |
Screw drive power | KW | 18.5 | 22 |
Output of HDPE | KG/H | 75 | 100 |
Oil pump drive power | KW | 7.5 | 7.5 |
Clamping force | KN | 65 | 80 |
Max.size of mold | MM | 320×350 | 400×430 |
Template size | MM | 290×320 | 380×420 |
Mold stroke | MM | 150-500 | 170-520 |
Max.die diameter | MM | 170 | 170 |
Size of machine | L×W×H | 3.9×2.2×2.6 | 4.2×2.2×2.7 |
Weight of machine | TON | 6.5 | 7.5 |
