Semi Automatic 5L PET Bottle Making Factory Plastic Blow Molding Machine


Semi Automatic 5L PET Bottle Making Heater with Blower Factory Plastic Jar Blow Molding Machine

Availability:
Quantity:

DAWSON MACHINERY & MOULD GROUP

Semi Automatic PET Bottle Blow Molding Machine


PET Bottle Blowing Molding Machine: Precise Control and High - performance

Microcomputer - controlled Technology


The PET bottle blow molding machine is equipped with microcomputer - controlled technology, enabling precise control over the plastic blowing process. The microcomputer system acts like a precise conductor, capable of fine - tuning various technical parameters. Whether it's the heating temperature of the plastic, the blowing pressure, or the molding time, all key indicators can be accurately controlled. This makes the plastic blow molding machine highly stable during the production process, ensuring the quality of products.

Precise control of technical parameters


Under the control of the microcomputer, the plastic blow molding machine can more accurately control technical parameters. For instance, by precisely controlling the blowing pressure, the thickness of the bottle body can be made uniform, avoiding uneven thickness. In terms of temperature control, the microcomputer can monitor the temperature changes of the heating device in real - time, ensuring that the plastic raw materials are blown at the appropriate temperature. This precise control not only improves product quality but also effectively reduces waste during the production process.

Advanced system configuration

Upper and lower system


The blow molding machine is equipped with an upper and lower system to ensure the smooth progress of the production process. The upper system is responsible for transporting the plastic raw materials to the blow mold, while the lower system pushes out the formed products. This coordinated working mode increases production efficiency and reduces production - related malfunctions.

Emergency stop system


To ensure production safety, the blow molding machine is equipped with an emergency stop system. When an unexpected situation or equipment failure occurs, the operator can quickly press the emergency stop button, immediately stopping the machine's operation. This system effectively prevents potential casualties and equipment damage caused by accidents.

Independent counter device


The independent counter device can accurately count the output quantity of products. Through precise counting, production personnel can keep track of the production progress in real - time and adjust the production plan accordingly. This helps improve production efficiency and ensure that the quality and quantity of products meet the requirements.

Heating device

Infrared lamp heating device


The infrared lamp heating device is an important part of the blow molding machine. It utilizes the principle of infrared radiation to quickly heat the plastic raw materials to the required temperature. The infrared lamp heating has strong penetrability and fast heating speed, enabling the plastic raw materials to be evenly heated in a short time.

Penetrating power


The infrared lamp heating device has a strong penetrating power, which can effectively penetrate the plastic raw materials, making the heating more uniform. This highly efficient heating method not only improves production efficiency but also ensures product quality.

pre - form rotation heating


The pre - form rotation heating is a unique design of the blow molding machine. It heats the plastic raw materials in a rotating way, allowing the plastic raw materials to rotate during the heating process, thus achieving uniform heating. This heating method enables the plastic raw materials to be more fully integrated during the heating process, improving product quality and stability.

Scope of application


The PET semi - automatic plastic bottle blow molding machine is suitable for the blow molding of various plastic PET bottles, such as carbonated beverage bottles, mineral water bottles, cosmetic bottles, and hot - filling bottles. These bottles have a large market demand and require high - level production processes. The blow molding machine can meet the production requirements of different types of bottles, providing an efficient and stable production solution for enterprises.

In conclusion, the PET bottle blow molding machine, with its advanced microcomputer - controlled technology, precise technical parameters, complete system configuration, and efficient heating device, has become an important equipment in the plastic bottle production field. It not only improves production efficiency and product quality but also provides strong support for the development of enterprises.


Main machine (blower + oven)

Item

YD-2L-4

Product Spec

Max. product volume(L/cav)

2L

Max. preform neck size(mm)

100

Max. product diameter(mm)

180

Max. product height (mm)

300

Cavities

4

Blow molding part

Die force (KN)

100

Die stroke (mm)

270

Max. mould size(mm)

390*345

Mould thickness

Adjustable

Mould spacing(mm)

Adjustable

Max. pulling stroke(mm)

400

Operation pressure(Mpa)

0.8-1.0

Operation air pressure consumption

(1tr/min)

200

Blow pressure(Mpa)

1.2-2.8

Blow air pressure consumption (1tr/min)

300

Output(pcs/h)

2600-2800(500ml bottle)

Machine size(LxWxH)(m)

1.46*0.58*1.8

Machine weight(KG)

650

Oven

Temperature grade(rate)

8

Heating time(S)

90-200

Voltage(V)

220 or as your request

Frequency(HZ)

50/60

Total power(KW)

16

Oven Size (LxWxH)

1.35*0.55*1.15

Oven weight (KG)

300
